Kivi Pekka 4
Best For:
Cost Effective, undulating terrain, power house
Working Width:
4 m
Stone Size:
2.5cm to 35cm
Hopper Size:
4 mᶟ
Kivi Pekka 4 - Overview
The KIVI-PEKKA 4 is the original model that established the KIVI-PEKKA reputation for reliable, efficient stone picking. Offering an excellent balance of capacity, manoeuvrability and productivity, it has become a proven performer for mixed farming enterprises, broadacre operations and agricultural contractors alike.
Designed to efficiently collect both small and large stones, the KIVI-PEKKA 4 helps create cleaner paddocks while protecting valuable cultivation, seeding and harvesting equipment from unnecessary wear and damage. Its durable construction, low-maintenance design and straightforward operation have made it a trusted choice for farmers looking for dependable performance season after season.
Combining practical engineering with proven reliability, the KIVI-PEKKA 4 continues to be one of the most versatile models in the range and an excellent choice for those wanting outstanding value without compromising on productivity.
Specifications:
Drive Hydraulic or PTO
Weight 4300 kg
Working width 400 cm
Stone size 2,5 – 35 cm
Output 700 kg/min
Stone hopper volume 3 m³
Tyre size 560/60-22.5
Power requirement 70 hp
Hydraulics 20 L oil/min (PTO Drive) 60L/min (Hydraulic Drive)
Running speed 1 – 6 km/h
Lifting drum tines 18 pcs
Tipping height 290 cm
Accessories (Standard)
PTO Drive
Hydraulic rake lift
Soil container
Trailer coupling
All PTO shafts
Hydraulic working depth adjustment
Sieve (in cultivation direction)
Walking tandems on rakes
Parts box
Tipping height 290 cm
Straight belts for lifting drum transmission
Strong tines 12×45
Robust rake pivots
Tyres 560/60×22.5
Accessories (Optional)
Hydraulic Drive Upgrade
ISO-BUS Compatible
📹 See it Working
FAQ’s
What Tractor Size is recommended?
You only need 70hp. The large hopper is balanced to the chassis when raised so you don’t need a large tractor to counter balance the weight of the hopper fully raised.
Can the Kivi Pekka 4 pickup Timber?
Yes, the KP 4 successfully picks up sticks, orchard pruning and even ex. tree country. Depends on timber size and length.
Do you have to replace a Spring Drum Tine if it breaks?
You can keep operating the picker with a broken tine (same as all Kivi Pekka models). It will still successfully pickup rocks with a broken tine or two, and you can replace the tine when you conduct your daily machine checks.
What is the required operating speed while picking rocks?
1 to 6km/hr is the required speed. This allows the best picking job while driving slow enough to prevent any damage by hitting a reef rock. I’m talking damage to the tractor drawbar.
What happens when you hit a reef rock while picking?
The drawbar cylinder has a “rock jump” assembly that allows the picker to jump over a large reef rock that prevents damage to the rear of the tractor. The Kivi Pekka stone pickers are design to handle hitting reef rocks, but is your Tractor?
